HIS HD 2600XT 256MB GDDR4 PCIe
Product CodeH260XT256G4DD-R
CoolerSingle-Slot Cooler
GPU2600XT
Core Clock800 MHz
Memory Clock2200 MHz
Memory Size256 MB
Memory TypeGDDR4
Memory Interface128 bit
InterfacePCI-Express x16
AvailabilityDiscontinued
  • Powered by Radeon® HD 2600XT GPU - 800MHz
  • Superscalar unified shader architecture
  • 120 stream processing units
  • 256MB 128-bit GDDR4 - 2200MHz
  • Comprehensive DirectX® 10 support
  • Integrated CrossFireTM
  • Built-in HDMI and 5.1 surround audio
  • Dynamic geometry acceleration
  • Game physics processing capability
CHIPSET FEATURES
  • 390 million transistors using 65nm fabrication process
  • Superscalar unified shader architecture
  • 120 stream processing units
  • 128-bit GDDR4 memory interface
  • Comprehensive DirectX® 10 support
  • CrossFireTM multi-GPU
  • High-speed 128-bit HDR lighting
  • Up to 24x Custom Filter Anti-Aliasing
  • ATI AvivoTM HD Video and Display architecture
  • Built-in HDMI and 5.1 surround sound
  • Support for the ATI RadeonTM DVI to HDMI adapter
  • Unified Video Decoder (UVD) for Blu-rayTM and HD DVD
HIS PRODUCTS ADVANTAGE
  • HIS Radeon™ HD 2600 XT delivers remarkable gaming performance for Windows Vista™ and DirectX® 10
  • HIS Radeon™ HD 2600 XT features hardware HD video processing and HDMI with built-in 5.1 surround audio
  • ATI Avivo™ HD technology delivers sharp images and vibrant color fidelity from 1080p playback of Blu-ray™ and HD DVDs movies
  • HIS Radeon™ HD 2600 XT delivers powerful graphics performance to enhance the stunning Windows Vista™ user experience
  • 65nm process – internal power on all skus
Pcie
ACCESSORIES
SOFTWARE BUNDLED
  • Half-Life®2:Lost Coast, Half-Life®2: Deathmatch(OPTIONAL)
  • Black Box game bundle from Valve Corporation(OPTIONAL)
  • Driver disc
CABLE/ADAPTOR BUNDLED
  • HDTV Cable
  • S-Video Cable
  • DVI to VGA/D-sub Adapters
  • Crossfire Bridge
  • DVI to HDMI Dongle
Model Name
Chipset
Radeon HD 2600 PCIe Series
ASIC
Pixel Pipelines
120 stream processing units* (Unified)
Vertex Engines
Manu. Process (Micron)
65nm
Transistor
180 million transistors on 65nm fabrication process
Fill Rate
Memory Size (MB)
256
Memory Type
RAMDAC (MHz)
400
Engine CLK (MHz)
Memory CLK (MHz)
2200
Memory Interface (bit)
Memory Bandwidth
Max. Resolution
2560*1600
Bus Interface
Power Supply Requirement
Connection to 400 Watt (550 for CrossFire™) or greater power supply with two 2x3-pin PCIe® power connectors is required.
VGA
No
2nd VGA
DVI
Yes
2nd DVI
TV-out
Yes
HDTV (YPrPb component output)
Video-in
No
TV Tuner
FM Tuner
No

ATI Radeon HD 2600 System Requirements

  • PCI Express® based PC is required with one dual-width X16 lane graphics slot available on the motherboard
  • AMD Athlon® or Intel® Pentium
  • 1GB of system memory
  • Connection to 400 Watt (550 for CrossFire™) or greater power supply with two 2x3-pin PCIe® power connectors is required.
  • Certified power supplies are strongly recommended. Refer to http://ati.amd.com/CertifiedPSU for a list of Certified products
  • Certified system cases with good airflow and cooling are recommended. Refer to http://ati.amd.com/certifiedcases for a list of Certified products
  • Installation software requires CD-ROM drive
  • To complete the CrossFire™ platform, a second ATI Radeon™ HD 2600 graphics card, a CrossFire™ Ready motherboard and one CrossFire™ Bridge Interconnect cable per board are required
Slot

Remarkable Gaming Performance for DirectX® 10
HIS Radeon™ HD 2600 XT delivers remarkable gaming performance to unleash the HD visual effects within Windows Vista™ and DirectX® 10. Plug-n-play CrossFire™ upgradeability makes it easy to scale up graphics performance to boost the most demanding games; and built-in multichannel 5.1-surround audio over HDMI establishes a new level of entertainment designed for tech savvy gamers.

Dual Width X16 Graphics Slot

ATI Avivo™ HD Video & Media
HIS Radeon™ HD 2600 XT features advanced hardware HD video processing and HDMI with built-in 5.1 surround sound for stunning big-screen entertainment. Home theater aficionados will be mesmerized by ATI Avivo™ HD technology that delivers sharp images and vibrant color fidelity from 1080p playback of Blu-ray™ and HD DVDs movies.

Certified for Windows Vista™
HIS Radeon™ HD 2600 XT delivers powerful graphics performance to enhance the stunning Windows Aero™ user interface. ATI Catalyst™ graphics management software is Certified for Windows Vista™ and is designed for quick and easy setup of graphics, video, and multiple displays.
